v. dipesh kumar & co. offers rangE
|
Champion Jointing Sheets And Gaskets |
|
| |
|
 |
|
1. Compressed Asbestos
Fibre (CAF) Jointiing Sheets in both
metallic and Non-metallic varieties of
all grades.
2. Compressed Non-Asbestos (Asbestos
Free) Fibre Jointing Sheets of all
grades.
3. Spiral Wound-Gaskets filled with CAF/Flexible
pure Graphite / PTFE |
|
 |
| CHAMPION
Style 20
STEAM |
Description:
Compressed Asbestos Fibre Jointing
is a consistently uniform
and resilient product. A price
worthy quality of dependable
performance,
plus adaptability to many sealing
requirements makes this 'STEAM'
JOINTING the choice sheet packing of
Plant Engineers and Maintenance men.
CHAMPION STYLE 20 Jointings are
developed for general purpose
applications and this quality is
applicable to a wide range of duties
with less severe working conditions
of temperature and pressure. |
|
|
IDENTITY COLOUR |
RED
OR GRAPHITED |
|
TECHNICAL DATA |
|
Recommended Maximum Temperature |
3800C |
|
Recommended Maximum Pressure |
35
Kg/sq.cm. |
Specification Compliance
(IS 2712-1998 Grade W/3),
(IS 2712-1971 Grade C.) |
|
|
|
 |
| CHAMPION
Style 20
METALLIC |
Description:
A Compressed Asbestos Fibre Jointing
with wire gauze insertion
supplied with Graphite Finish, Used
for general purpose application
where
conditions of temperature and
pressure are not too serve.
|
IDENTITY COLOUR |
GRAPHITED
BLACK |
|
TECHNICAL
DATA |
|
|
Recommended Maximum
Temperature |
4150C |
|
Recommended Maximum
Pressure |
40
Kg/sq.cm. |
|
|
|
 |
|
CHAMPION
Style 54
SUPER |
Description: Manufactured from
excellent quality of Chrysotile Asbestos
Fibre and raw materials, the blend being
intimately mixed with heat resisting
rubber compounds under special process,
to ensure maximum stability against high
pressure and temperatures. Though
primarily a super heated steam Jointing
it is also recommended against saturated
Steam, Oxygen,
Petroleum distillates, oils and fats,
fuels, internal combustion engines,
hydrocarbons, alcohols, solvents, lyes,
etc. It is popularly used in MARINE
ENGINES,electricity generating sets etc. |
|
IDENTITY
COLOUR |
YELLOW/GREY
OR GRAPHITED |
|
TECHNICAL DATA |
|
Recommended Maximum Temperature |
5500C |
|
Recommended Maximum Pressure
|
150 Kg/sq.cm. |
Specification Compliance
(Indian IS 2712-1998 Grade W/1),
(IS 2712-1971 Grade A/S),
(DGS & D G/MISC/81-C item 12 (a)
Special Quality)
(British BS 2815-1973 Grade A) |
|
|
|
 |
|
CHAMPION
Style 39
HIGH PRESSURE |
Description:
Manufactured from selected quality
of Asbestos Fibre and
vulcanized with special rubber
compound to meet with the exacting
requirements of modern industry.
Used for applications against dry
and wet steam, water, gases,
alkalies, oil at normal
temperatures, chemicals,fuels etc and general engineering.
CHAMPION :Style 39 can also be
provided with wire gauze insertion
in graphited finish. |
|
|
|
IDENTITY COLOUR |
BROWN/GREY
OR GRAPHITED |
|
TECHNICAL DATA |
|
|
Recommended Maximum Temperature |
4400C |
|
Recommended Maximum Pressure |
80 Kg/sq.cm. |
Specification Compliance
(Indian IS 2712-1998
Grade 0/2),
(IS 2712-1979 Grade W/2),
(IS 2712-1971 Grade B/S),
(British BS 2815-1973 Grade B) |
|
|
|
|
 |
| CHAMPION
Style 59
OIL |
Description:
A high grade Asbestos Fibre Jointing
bonded with a sophisticated compound, this
specialized jointing withstands the most exacting
demands of oil and Petrochemicals plants, solvents
refrigerator, oil etc. Used in pipe lines and
apparatus of the petrochemical fields, Petroleum
distillates, oil and petroleum refining
industries.It is also recommended in
industrial processes with high contents of aromatic
substances, sulphurous
compounds, chloric hydrocarbons, phenols,
refrigerants, etc. Use of CHAMPION oil jointing
sheet assures safety and economy even on critical
working conditions.The jointing gives satisfactory
services against steam also.
|
IDENTITY COLOUR |
DARK GREY |
|
TECHNICAL DATA |
|
|
Recommended Maximum Temperature |
5500C |
|
Recommended Maximum Pressure |
150 Kg/sq.cm. |
Specification Compliance
(Indian IS 2712-1998 Grade 0/1),
(IS 2712-1971 Grade A/O)
(DEFENCE TS RED/71/59),
(British BS 1832-1972) |
|
|
|
|
 |
| CHAMPION
Style 60
ACID |
Description:This is a specialised
Asbestos Fibre Jointing Sheet which is
intimately bonded with Acid resisting compound, to
withstand the corrosive action of acids and
chemicals, Recommended for use against hot
concentrated organic,Inorganic and mineral acids
including hydrochloric,
sulphuric (oleum) and nitric acids, under service
conditions of temperature and pressures commonly
encountered in Chemical industries.
|
IDENTITY COLOUR |
CREAM/LIGHT
GREY |
|
TECHNICAL DATA |
|
|
Recommended Maximum Temperature |
2100C |
|
Recommended Maximum Pressure |
150 Kg/sq.cm. |
Specification Compliance
(Indian IS 2712-1998 Grade A/1), |
|
|
|
|
MAJOR TECHNICAL
FEATURES |
|
STYLE |
TENSILE
STRENGTH N/mm2 |
STRESS
RESISTANCE N/mm2 |
Compressibility
% |
Recovery
% |
Ignition
Loss % |
Recommended
Maximum Temperature |
Recommended
Maximum
Pressure |
| 20 |
9.5 |
20 |
7.5-12 |
>
42.5 |
<
20 |
3800C |
35 Kg/sq.cm |
| 20 M |
12.0 |
20 |
7-12 |
> 45 |
<
20 |
4150C |
40 Kg/sq.cm |
| 39 |
18.0 |
23 |
7-12 |
> 45 |
<
22 |
4400C |
80 Kg/sq.cm |
| 54 Super |
28.0 |
28 |
6.5-11.5 |
> 50 |
<
25 |
5500C |
150 Kg/sq.cm |
| 54 Super M |
30.0 |
30 |
7-10.5 |
> 50 |
<
22 |
6000C |
160 Kg/sq.cm |
| 59 Oil |
28.0 |
30 |
7-10.5 |
> 50 |
<
25 |
5500C |
150 Kg/sq.cm |
| 60 Acid |
27.0 |
25 |
7-12 |
> 45 |
> 25 |
2100C |
150 Kg/sq.cm |
|
|
|
STYLE |
PRODUCT
PROFILE |
* SERVICE CONDITIONS |
TYPICAL
PHYSICAL
PROPERTIES |
FLUID RESISTANCE |
|
|
A cost
effective product
manufactured from
ecofriendly natural
cellulosic fibres bonded
with suitable mix of
elastomers.
Colour: Red & Green
Also available with wire
gauze reinforcement
and antistick coating.
|
General
purpose gasketing material suitable for use
with Oils, Solvents, Gases, Water, L.P.
Steam and most dilute acids and alkalies
(Low service conditions) Max. Operating
Pressure: 25 bars
Max. Short Term Service Temperature: 400°C
Max. Continuous Service Temperature: 250°C
Max. Operating Temperature for Steam : 180°C |
|
Density |
|
1.75 g/cm3 |
Tensile
Strength |
ASTM
F 152 |
8.5
MPa |
Compre
ssibility |
ASTM
F 36 |
8-13% |
|
Residual Stress |
BS
7531 |
22
MPa |
|
Gas Permeability |
BS
7531 |
<0.5
cc/Min |
|
Recovery |
ASTM
F 36 |
> 45% |
|
Water Absorbtion |
BS
7531 |
< 5% |
|
Ignition Loss |
|
< 40% |
|
|
ASTM Oil
No.3 |
Fuel B |
Thick
ness
Incre
ase% |
Mass
Incre
ase % |
Thick
ness
Incre
ase% |
Mass
Incre
ase % |
|
<
10 |
<
10 |
<
10 |
<
10 |
|
|
|
A
compressed synthetic
Aramid fibre jointing
sheet bonded with
elastomers to create a
matrix of stability
Colour: Green
Also available with wire
gauze reinforcement and
antistick coating. |
Suitable for light industrial
applications. Media: Water, Gases, Medium
Pressure Steam, Dilute Acids/Alkalies
(Medium Service Conditions)
Max. Operating Pressure : 50
bars Max. Short Term Service Temperature:
400°C Max. Continuous Service Temperature :
250°C
Max. Operating Temperature
for Steam: 200°C |
|
Density |
|
1.9
g/cm3 |
Tensile
Strength |
ASTM
F 152 |
11.5
MPa |
Compre
ssibility |
ASTM
F 36 |
8-11 % |
|
Residual Stress |
BS
7531 |
22
MPa |
|
Gas
Premeability |
BS
7531 |
<0.5
cc/Min |
|
Recovery |
ASTM
F 36 |
> 45 % |
Water
Absorbtion |
BS
7531 |
< 5% |
|
Ignition Loss |
|
< 30% |
|
|
ASTM Oil
No.3 |
Fuel B |
|
Thick
ness
Incre
ase% |
Mass
Incre
ase % |
Thick
ness
Incre
ase% |
Mass
Incre
ase % |
|
<
10 |
<
10 |
<
10 |
<
10 |
|
|
 |
A high quality
jointing sheet based on synthetic Aramid
fibres bonded with NBR elastomer. Colour:
Orange Also available with wire gauze
reinforcement and antistick coating. |
Suitable for
use in applications involving hydrocarbons
such as oils and solvents, steam, gases,
glycols and aqueous solutions.
(Medium Service Conditions)
Max. Operating Pressure: 80 bars Max. Short
Term Service Temperature: 400°C
Max. Continuous Service Temperature : 250°C
Max. Operating Temperature for Steam: 200°C |
| Density |
|
1.85
g/cm3 |
|
Tensile Strength |
ASTM
F 152 |
14
MPa |
Compress
ibility |
ASTM
F 36 |
8-12% |
Residual
Stress |
BS
7531 |
22 MPa |
|
Gas
Permeability |
BS 7531 |
<
0.5
cc/Min |
|
Recovery |
ASTM
F 36 |
> 40% |
|
Water
Absorbtion |
BS
7531 |
<
5 % |
|
Ignition Loss |
|
<
35% |
|
|
ASTM Oil
No.3 |
Fuel B |
|
<
8 |
< 8 |
< 8 |
< 8 |
|
|
 |
A superior
performance compressed jointing sheet
incorporating a blend of special heat
resisting Aramid fibres with a high quality
nitrile elastomer binder
Colour: Yellow
Also available with wire gauze reinforcement
and anti stick coating. |
Suitable for
use with Oils, Solvents, Gases, Steam,
Dilute Acids and alkalies.
(High Service Conditions)
Max. Operating Pressure :
150 bars
Max. Short Term Service Temperature: 450°C
Max. Continuous Service Temperature: 250°C
Max. Operating Temperature for Steam: 290°C |
| Density |
|
1.8
g/cm3 |
Tensile
Strength |
ASTM
F 152 |
15 MPa |
Compre
ssibility |
ASTM
F 36 |
7-11% |
|
Residual Stress |
BS
7531 |
25 MPa |
|
Gas
Permeability |
BS
7531 |
< 0.1
cc/Min |
|
Recovery |
ASTM F 36 |
>
50 % |
Water
Absorbtion |
BS
7531 |
<
5% |
|
Ignition Loss |
|
<
35% |
|
|
ASTM Oil
No.3 |
Fuel B |
|
<
8 |
<
8 |
<
8 |
<
8 |
|
|
|
A Premium
grade jointing sheet based on special
synthetic Aramid fibres bonded with nitrile
elastomer
Colour: Grey
Also available with wire gauze reinforcement
and antistick coating. |
A universal
grade suitable for many industrial sealing
applications. Media: Hot oils, fuels,
Hydrocarbons and refrigerants.
(High Service Conditions)
Max. Operating Pressure :
150 bars
Max. Short Term Service Temperature: 450°C
Max. Continuous Service Temperature: 250°C
Max. Operating Temperature for Steam: 250°C |
| Density |
|
1.7 g/cm3 |
Tensile
Strength |
ASTM
F152 |
15 MPa |
Compre
ssibility |
ASTM
F36 |
10-14 % |
|
Residual Stress |
BS
7531 |
25
MPa |
|
Gas
Permeability |
BS
7531 |
<0.1 cc/Min |
|
Recovery |
ASTM
F 36 |
>
45% |
Water
Absorbtion |
BS
7531 |
< 5% |
|
Ignition Loss |
|
< 35% |
|
|
ASTM Oil
No.3 |
Fuel B |
|
<
8 |
<
8 |
<
8 |
<
8 |
|
|
|
A top quality
acid resistant compressed synthetic Aramid
fibre jointing sheet bonded with special
binders.
Colour: Cream
Available with antistick coating.
|
Acid resistant
grade. Recommended for use against hot,
Concentrated Organic/inorganic/mineral
acids. Max. Operating Pressure :
150 bars
Max. Short Term Service Temperature: 250°C
Max. Continuous Service Temperature: 210°C
Max. Operating Temperature for Steam: 210°C |
|
Density |
|
1.8 g/cm3 |
Tensile
Strength |
ASTM
F 152 |
15 MPa |
Compre
ssibility |
ASTM
F 36 |
8-12 % |
Residual
Stress |
BS
7531 |
25 MPa |
|
Gas
Permeability |
BS
7531 |
< 0.1
CC/mIN |
|
Recovery |
ASTM
F 36 |
>
50% |
|
Water
Absorbtion |
BS
7531 |
<
5% |
|
Lgnition Loss |
BS
7531 |
<
35% |
|
Thick
ness
Increase
% |
Mass
Incre
ase
% |
Thick
ness
Incre
ase
% |
Mass
Incre
ase
% |
|
<
8 |
<
8 |
< 8 |
<
8 |
|
|
| Champion Spitmaan Charminar Caf Sheets
| Asbestos Packing |
Non-Asbestos Packings
|
| Asbestos Textile & Ceramic Products for Heat Insulation
| Pure / Filled PTFE / Teflon Products |
|
PTFE Thread Seal
| Teadit Non Asbestos Products
| Gaskets for Flanges /
Cork Products
|
| Fiber Nylon / Polyurethane Products | Fiber Products |
Nylon Products |
Polyurethane Products |
| Rubber Sheets & Parts
| Graphite & Carbon Products |
Plastic Products & Engineering Plastic |
| Tuff Seal Non Asbestos & Fluid Seal products
| |
|
|
